Commercial 1000l materials craft beer brewing equipment with stainless steel tank

  • >=1 Pieces
    $3,599.00
Model Number:
1000l 2000l
Lead Time:
Quantity(Pieces) 1 - 1 >1
Est. Time(days) 50 Negotiable
Customization:
Customized logo (Min. Order: 1 Pieces)
Customized packaging (Min. Order: 1 Pieces)

More

Graphic customization (Min. Order: 1 Pieces) Less
Samples:
$150.00 /Piece | 1 Piece (Min. Order) | Buy Samples
Report Suspicious Activity
Overview
Quick Details
Processing:
Fermenting Equipment
Condition:
New
Warranty:
3 years
After-sales Service Provided:
Field installation, commissioning and training
Place of Origin:
Shandong, China
Brand Name:
NDL Craft
Voltage:
220V/380V 50HZ/60HZ
Weight:
5000KGS
Processing Types:
1000L Beer Brewing Equipment
Certification:
CE ISO SGS
Dimension(L*W*H):
60-80㎡
Power(W):
20-80KW
Applicable Industries:
Hotels, Food & Beverage Factory, Restaurant, Retail, Food Shop, Food & Beverage Shops
After Warranty Service:
Video technical support, Online support
Local Service Location:
Canada, United Kingdom, United States, Germany, Australia
Showroom Location:
Canada, United Kingdom, United States, Germany, Australia
Keywords:
1000L Beer Brewing Equipment
Type:
2 vessls brewhouse
Function:
Commercial brewing
Material:
Sus304/316 optional
Cooling method:
Glycol water cooling method
Fermenter bottom cone:
60 degree
Insulation layer:
Polyurethane or rockwool
Cleaning:
Rotary washing ball and CIP tube
Control:
Temperature & pressure control
Heating method:
Electricity / Steam / Fire
Supply Ability
Supply Ability:
50 Set/Sets per Month 1000L Beer Brewing Equipment
Packaging & Delivery
Packaging Details
1.LCL or FCL 2.Plastic film, wooden case or iron fixation, to keep it safe 3.suitable for delivery, up to export standard for draft beer making machine , 1000L beer brewing equipment
Port
Qingdao
Picture Example:
package-img
Lead Time :
Quantity(Pieces) 1 - 1 >1
Est. Time(days) 50 To be negotiated

commercial 1000l materials craft beer brewing equipment with stainless steel tank



Product Description

      beer brewing equipment is more and more popular around the world. Many beer fans want to start home brewery, enjoy their life sharing own beer with family and friends, some home brewer plan to expand to commercial brewery of a brewpub or mini plant after years of experience, and some experienced brewer want to start own business after years' working in the big brewery company, and for the shaped microbrewery have plan to expand the production for the popular of their tasty beer, anyway, NDL Craft is your good choice to work together for your  craft beer brewing equipment.



Technical paraments

Name

Craft 1000L beer brewing equipment

Miller

Miller with double roller

Brewhouse System

Including Mash/Lauter tun, Kettle/Whirlpool tank;

Heating way: Electric or steam heating;

With raker, false bottom, spray ball etc;

Fermenter

Fermentation tanks

(the capacity is based on the brew batch; the quantity is based on

the production);

Other accessories are available: 1. L-Pipe; 2. Butterfly Valve; 3. Pressure Gage; 4. Solenoid Valve; 5. Vacuum Valve; 6. Cooling Pipe; 7. Thermal Insulation Pipe;

Glycol cooling unit

Ice water tank, Refrigeration Machine;
Sanitary centrifugal pump for glycol water recycle among tanks and heat exchanger;
All pipes, fitting, insulation materials are included.

CIP cart

Sterilization Tank ,Caustic tankThickness is 2mm;

Weld slinging band;

Valves, accessories supporting;All welding are argon protection single-sided,

double-sided forming;

Function:Clean in place for tanks

Control panel

PID semi-auto controller, PLC auto controller, brand is Siemens, Schneider,

LG for optional.
Electric components have CE Certificate.
Offer floor type and wall hanging assembling.
Control all the tank’s temperature, motor and pump's show on/off.

Filter Unit

Kieselguhr filter, Membrane filter;

Filtered beer tanks/bright beer tank;

In restaurant, beers are always served as craft beer without filtration.

Filling  system

 Keg filling and washing Machine;

 Bottle capping and filling Machine.

Other facilities

Hopback machine, boiler, and so on .

Product Descrition
Beer Brewing Equipment processing main configuration:



Malt Milling Unit

1.    Particle adjustable rolling crusher

2.    Flexible or steel auger for optional



Brewhouse Unit

1.    Mash tun, Lauter tun, Boiling Kettle, Whirlpool tun in various combination

2.    Hot water tank and cold water tank for optional in special combinations

3.    Infusion or decoction brewing methods are designed exactly

4.    Stainless steel or copper cladding are popular

5.    Two stages or single stage heat exchanger for wort cooling

6.    Completely stainless steel integrated work platform

7.    Sanitary and efficiency wort pump

8.    All pipings and fittings

A typical 2 vessels:



Combination Mash Lauter Tuns are the first combination vessel in these smaller brewhouses line ups. This vessel should be sized to favor the Lauter operation, and have the mechanics for mixing mash and graining out.



Next inline is the combination of the Kettle and Whirlpool tanks. This combination vessel is designed and sized for being primarily a kettle, but is equipped with a tangential fitting for whirlpooling.



Fermentation Unit

Fermentation tanks are where the magic happens. It’s important to have a precisely built vessel to condition your beer as it ferments. NDL Craft offers fermentation tanks with ultra-precise welding and polishing, complete traceability, and material exactness to meet all international safety standards. From small, pub-size fermenters to towering outdoor tanks, we have the manufacturing capability and expertise to custom-build fermentation tanks of all sizes.

1.   Standard stainless steel conical cylindrical fermentation tanks

2.    Single size as brewhouse is common used in restaurant

3.    Tanks quantity is exactly calculated by fermentation cycle for various beers

4.    All manhole, valves, pressure gauges, fittings etc are included



Bright Tank Unit

1.Standard stainless steel bright tanks for beer maturation, conditioning, service, carbonation

2.   Single size as fermenter is common used in restaurant or bar

3.   Tanks quantity is exactly calculated for various beers and the function

4.   All manhole, valves, stone, gauges, fittings etc are included



Cooling Unit

 1.Insulated glycol water tank with or without copper coil for glycol liquid holding and mixing

2. Efficiency chillers or refrigerators with fryonto supply cooling energy

3. Sanitary centrifugal pump for glycol water recycle among tanks and heat exchanger

4. All pipes, fitting, insulation materials are included



Controlling Unit

1.  Electrical controlling cabinet with temperature, on-off controlling for brewhouse

2.  Electrical controlling cabinet with temperature, on-off controlling for cooling parts

3. Temperature controller, thermocouple, solenoid valves etc are included

4.  PLC with touch screen panel for special request



NDL Premium Products

Our service

a. Free consultation service before, during, and after sales

b. Project planning and design services

c. Free debugging instruction of equipment until everything is functional

d. Management of equipments' long distance shipping from seller's factory to named port or station by buyer

e. Training of equipment maintenance and operating personally

f. New production techniques

g. Provide 36 months complete warrantee for main parts and life-time maintenance service;The seller is responsible for the nature damage of the machinery in the warranty period except for man-made damage. All spare parts and wearing parts are attached with the machinery for free

All beer brewing equipment for sale spare parts and wearing parts are attached with the machinery for free freely.

Company Information

Company Profile

NDL Craft, founded in 2011, is a brewing equipment manufacturer and brewing technology engineering company that provides many kinds of customized tanks and turnkey projects throughout the world. The company attaches great importance to the research and development of core technology. On the basis of maintaining the manufacturing cost of China, the company can design according to CE PED standards and ASME design codes, and institutes production and quality control methods according to both European and American quality standards.

Certificates

NDL Craft has passed quality audits for internationally recognized certifications; ISO9001, 2000 International Quality Management System Certification,
ISO14001 Environmental Certification,
ISO18001 Occupational Health and Safety System Certification,
DI, and DII Pressure Vessel Certification.
We have also been recognized at a national-level as a scientific and technological innovation enterprise with 15 patented technologies granted in China.

Exhibition for NDL Craft

    Sincerely look forward to cooperating with you and become your career development of strong backing.We welcome cooperation with you, to undertake various kinds of beer brewing .

    NDL Craft attended many exhibtions each year, we attended few proffessional exhibition in Shanghai and other countries, such as US, one exhibition in Shnghai, one exhibition in America, one exhibition in Germany and several exhibitions in domestic. We showed our beer brewing system.



Sale Cases





Contact Us

Please feel free to contact if interested in our products

We want to know:

1. Which capacity do you need?

2. Used for home brew/pub/restaurant or brewery plant?

3. Plan of your project?



Perfect Brewery Equipment, for Beer with Character

-With the best cost performance

We are not the biggest enterprise, but we supply the good equipment with competitive price. We are doing our best to help customers realize their brewery dream within their budget.

-Rising quality

Everything we do, we do with a meticulous eye for the maximum level of Quality, Consistency and Durability. We are certificated by CE and ISO.

-Wholeheartedly service

We are your partner throughout the entire brewery development process. We will be as involved as you are comfortable with; it's an honor to be a part of your team. Always at your fingertips - you can count on us for solutions, not just some tanks and pipes.

-With Trade Assurance Granted by Alibaba.com

We have Trade Assurance granted by Alibaba.com, it's seen as Buyer Protection.  protected, payment safety, timely shipment; 100% of assurance amount refu
